HIKVISION
HWN-4216MH-16P(E)
Ip recorder of 16 channel and 8 mpx resolution with 16 PoE ports
- IP Channels: 16
- Maximum recording resolution: 8 Mpx
- PoE ports: 16
- Input bandwidth: 160Mbps
Sign in to see the price
Quantity1
accessories
- 1
Inputs/Outputs
USB 2.0: 2
- 2
Recording
Maximum recording resolution: 8 Mpx
Input bandwidth: 160Mbps
Output bandwidth: 80Mbps
- 3
Video output
HDMI Output Number: 1
Number of VGA outputs: 1
- 4
Network features
Number of ports RJ45: 1
Speed RJ45: 10 / 100 / 1000 Mbps
- 5
Storage
Number of supported hard drives: 2
Maximum hard disk size (Unit): 8 TB
HIKVISION
HWN-4216MH-16P(E)
specifications and features
General information
SerieSerie 4
TechnologyIP
CompatibilityHikvision HA series cameras
Power consumption
Power modeAC
Voltage100V ~ 240V
Consumption (w)280W
Ambient
Operating temperature-10 ºC ~ 55 ºC
Maximum humidity90%
Material and dimensions
InstallationDesktop
Dimensions385 x 315 x 52 mm
MaterialMetal
Net weight2600 g
Chassis1U
Inputs/Outputs
USB 2.02
Video
IP Channels 16
Recording
Maximum recording resolution8 Mpx
Input bandwidth160Mbps
Video compressionH.265+ / H.265 / H.264+ / H.264
Audio compressionG.711A / G.711U / G.722 / G.726
Resolutions4K / 6Mpx / 5Mpx / 4Mpx / 3Mpx / 1080P / UXGA / 720P / VGA / 4CIF / DCIF / 2CIF / CIF / QCIF
Output bandwidth80Mbps
Video output
HDMI Output Number1
Number of VGA outputs1
Resolution HDMI4K
VGA resolution1080P
Similar video signalsHDMI and VGA
Audio
Audio Inputs1
Audio Outputs1
Network features
PoE ports16
Number of ports RJ451
Speed RJ4510 / 100 / 1000 Mbps
Maximum number of users32
Mobile devicesAndroid / IOS (Apple)
Remote visionWeb Browser / Smartphone App and Hik-Connect Software.
Type PoE802.3at / af
PoE consumption150W
SoftwareIVMS
AppHik-Connect
Reproduction and copy of security
Smart searchYes
Synchronized playback16
Storage
Number of supported hard drives2
Maximum hard disk size (Unit)8 TB
Type HDD3,5 SATA"
Intelligent video system
Motion detectionYes, 2.0 in 4 channels
