HIKVISION
HWN-4208MH-8P(E)
Ip recorder of 8 channel and 8 mpx resolution with 8 PoE ports
- IP Channels: 8
- Maximum recording resolution: 8 Mpx
- PoE ports: 8
- Input bandwidth: 80Mbps
Sign in to see the price
Quantity1
accessories
- 1
Inputs/Outputs
USB 2.0: 2
- 2
Recording
Maximum recording resolution: 8 Mpx
Input bandwidth: 80Mbps
Output bandwidth: 80Mbps
- 3
Video output
HDMI Output Number: 1
Number of VGA outputs: 1
- 4
Network features
Number of ports RJ45: 1
Speed RJ45: 10 / 100 Mbps
- 5
Storage
Number of supported hard drives: 2
Maximum hard disk size (Unit): 6 TB
HIKVISION
HWN-4208MH-8P(E)
specifications and features
General information
SerieSerie 4
TechnologyIP
Power consumption
Power modeAC
Voltage100V ~ 240V
Consumption (w)15W
Ambient
Operating temperature-10 ºC ~ 55 ºC
Maximum humidity90%
Material and dimensions
Dimensions385 x 315 x 52 mm
Net weight2600 g
Chassis1U
Inputs/Outputs
USB 2.02
Video
IP Channels 8
Recording
Maximum recording resolution8 Mpx
Input bandwidth80Mbps
Video compressionH.265+ / H.265 / H.264+ / H.264
Resolutions4K / 6Mpx / 5Mpx / 4Mpx / 3Mpx / 1080P / UXGA / 720P / VGA / 4CIF / DCIF / 2CIF / CIF / QCIF
Output bandwidth80Mbps
Video output
HDMI Output Number1
Number of VGA outputs1
Resolution HDMI4K
VGA resolution1080P
Independent video signalsYes
Audio
Audio Outputs1
Audio bidirectional (Full-duplex)Yes
Network features
PoE ports8
Number of ports RJ451
Speed RJ4510 / 100 Mbps
Mobile devicesAndroid / IOS (Apple)
Type PoE802.3at / af
PoE consumption80W
SoftwareIVMS
AppHik-Connect
Reproduction and copy of security
Smart searchYes
Synchronized playback8
Storage
Number of supported hard drives2
Maximum hard disk size (Unit)6 TB
Type HDD3,5 SATA"
Intelligent video system
VCASí
