MILESIGHT
MS-C8175-FPC-B
Minidome ip camera of 8 megapíxeles and optical zoom lens
- Video Resolution: 8 Megapixels
- Lens Type: Optical zoom
- Serie: AI Mini Camera Series
- Focal distance: 2.7 mm ~ 13.5 mm
Sign in to see the price
Quantity1
accessories
- 1
Ambient
Degree of protection: IP67
Anti vandal: IK10
- 2
Night vision
Night vision distance: 50 m
- 3
Lens
Lens Type: Optical zoom
Focal distance: 2.7 mm ~ 13.5 mm
- 4
Video (Cameras)
Video Resolution: 8 Megapixels
- 5
Storage
MicroSD-Card: Up to 256Gb
detect
fixed lensvarifocal lens
84 m / 420 m
perception of moving objects without classifying them
observe
fixed lensvarifocal lens
33 m / 165 m
differentiation between people, animals or vehicles
recognise
fixed lensvarifocal lens
17 m / 83 m
distinction between a man or a woman
identify
fixed lensvarifocal lens
8 m / 41 m
facial identification, number plate visualisation
MILESIGHT
MS-C8175-FPC-B
specifications and features
General information
SerieAI Mini Camera Series
TechnologyIP
Type of cameraMinidome
SensorCMOS ®
Sensor resolution3840 x 2160
Sensor Size1/2.8'
Electronic shutter speed1s to 1/100,000s
Minimum lighting0.01Lux
Ratio S / NMore than 55dB
Power consumption
Consumption (w)9W
PoE powerYes
Type PoEPoE 802.3af
Ambient
Operating temperature-40 ºC ~ 60 ºC
Degree of protectionIP67
Anti vandalIK10
UseIndoor-outdoor
Maximum humidity90%
Night vision
Night vision distance50 m
Smart IRYes
StarlightYes
Material and dimensions
Dimensions115 x 130 (Ø) mm
Net weight780 g
ColorBlack
Lens
Lens TypeOptical zoom
Focal distance2.7 mm ~ 13.5 mm
Maximum diaphragm openingF/1.4
Angle of View107° ~ 33°
AutofocusYes
DISTANCE DORI
Detect (Open lens)84 m
Detect (Closed Lens)420 m
Observe (Open lens)33 m
Observe (Closed lens)165 m
Recognize (Open lens)17 m
Recognize (Closed lens)83 m
Identify (Open lens)8 m
Identify (Closed lens)41 m
Axes
Motion3-Axis
Video (Cameras)
Video Resolution8 Megapixels
BLCYes
HLCYes
3D-NRYes
AGCYes
AWBYes
WDRWDR (120 dB)
Images per second25fps
Video outputRJ45
Day / night modeAutomatic / Manual
Privacy maskUp to 28 areas
Anti fog systemYes
Type of CodexCBR / VBR
Bit rate16Kbps ~ 16Mbps
CompressionH.265+ / H.265 / H.264
EISYes
Main stream4K / 6Mpx / 5Mpx / 4Mpx / 3Mpx / 1080P / 1.3Mpx / 720P / 704 x 576 (1 ~ 25fps)
Sub stream704 x 576 / 640 × 480 / 640 × 360 / 352 x 288 / 320 x 240 / 320 x 192 / 320 x 180 (1 ~ 25fps)
Sub stream 21080P / 720P / 704 x 576 / 640 × 480 / 640 × 360 / 320 x 240 / 320 x 192 / 320 x 180 (1 ~ 25fps)
WatermarkYes
Anti flapYes
AUDIO(CAMERAS)
Built in microphoneYes
Audio compressionG.711 / G.722 / G.726 / AAC
Sampling frequency8 kHz 16 kHz 32 kHz 44.1 kHz 48 kHz
Bit rate 16 Kbps ~ 256 Kbps
Network features
IP connection1 RJ45 (10M / 100M)
ONVIFYes, type S, G, T and Q
Management softwareMilesight CMS
IP address filterYes
Network disconnectionYes
Video analysis
Crossing lineYes
Face detectionYes
Motion detectionYes
Abandoned objectYes
Missing objectYes
Video TamperYes
HeatmapYes
People countingYes
Loitering detectionYes
Classification Human / vehicleYes
Storage
MicroSD-CardUp to 256Gb
Storage Systems NAS / Micro SD / Recorder
ANR (Redundant Recording in SD)Yes
DORI distance
Detect84 m / 420 m
Observe33 m / 165 m
Recognise17 m / 83 m
Identify8 m / 41 m
