AJAX
MOTIONCAMOUTDOOR-PHOD-W
Wireless volumetric double technology detector
- Grade: 2
- Detector type: Wireless
- Type of sensor: 2 x passive infrared sensors
- Installation height: 0.8 m ~ 1.3 m
Sign in to see the price
Quantity1
accessories
- 1
Certification
Grade: 2
- 2
SENSOR
Type of sensor: 2 x passive infrared sensors
- 3
DETECTION
Detector type: Wireless
Pets immunity: Up to 80 cm
Detection technology: Volumetric double technology
AJAX
MOTIONCAMOUTDOOR-PHOD-W
specifications and features
General information
CompatibilityHub 2 / Hub 2 Plus / Hub Hybrid a partir de la versión OS Malevich 2.13
Power consumption
Battery model4 x CR123A
Battery durationUp to 3 años
Ambient
Operating temperature-25 ºC ~ 60 ºC
Degree of protectionIP55
UseOutdoor
Maximum humidity95%
Material and dimensions
Dimensions206 x 108 x 93 mm
Net weight470 g
Weight with packaging750 g
Certification
Grade2
NormativeEN50131
Via Radio
Frequency868.0 MHz ~ 868.6 MHz
Transmission distance Up to 1700 m (without obstacles)
Maximum power RFHasta 20 mW
TECHNICAL SPECIFICATIONS
LED indicatorsYes
TamperYes
SENSOR
Type of sensor2 x passive infrared sensors
Double PIR sensorSí
Sensitivity adjustmentSí
Verificación fotografica
Angle of view105º horizontal / 50º vertical
Foto bajo demanda (PhOD)Yes
DETECTION
Detector typeWireless
Installation height0.8 m ~ 1.3 m
Angle detection90º
Detection distanceAdjustable 3m ~ 15m
Detection speed0,3 m/s ~ 2 m/s
Pets immunityUp to 80 cm
AntimaskingYes
Detection technologyVolumetric double technology
