HIKVISION PRO
DS-7608NXI-I2/8P/S(E)
Ip recorder of 8 channel and 12 mpx resolution with 8 PoE ports
- IP Channels: 8
- Maximum recording resolution: 12 Mpx
- PoE ports: 8
- Input bandwidth: 80Mbps
Sign in to see the price
Quantity1
accessories
- 1
Inputs/Outputs
Alarm input: 4
USB 2.0: 1
USB 3.0: 1
Alarm output: 1
- 2
Recording
Maximum recording resolution: 12 Mpx
Input bandwidth: 80Mbps
Output bandwidth: 256Mbps
- 3
Video output
HDMI Output Number: 1
Number of VGA outputs: 1
- 4
Network features
Number of ports RJ45: 1
Speed RJ45: 10 / 100 / 1000 Mbps
- 5
Storage
Number of supported hard drives: 2
Maximum hard disk size (Unit): 10 TB
HIKVISION PRO
DS-7608NXI-I2/8P/S(E)
specifications and features
General information
SeriePRO
TechnologyIP
Power consumption
Power modeAC
Voltage100V ~ 240V
Consumption (w)15W
Ambient
Operating temperature-10 ºC ~ 55 ºC
UseIndoor
Maximum humidity90%
Material and dimensions
Dimensions385 x 315 x 52 mm
MaterialMetal
Net weight2700 g
Weight with packaging3500 g
Chassis1U
Inputs/Outputs
Alarm input4
USB 2.01
USB 3.01
Alarm output1
Video
IP Channels 8
Recording
Maximum recording resolution12 Mpx
Input bandwidth80Mbps
Video compressionH.265+ / H.265 / H.264+ / H.264
Audio compressionG.711A / G.711U / G.722 / G.726 / MP2L2
Resolutions12Mpx / 4K / 6Mpx / 5Mpx / 4Mpx / 3Mpx / 1080P / UXGA / 720P / VGA / 4CIF / DCIF / 2CIF / CIF / QCIF
Output bandwidth256Mbps
Video output
HDMI Output Number1
Number of VGA outputs1
Number of BNC outputs1
Resolution HDMI4K
VGA resolution1080P
Resolution BNC704 x 576
Independent video signalsYes
Audio
Audio Inputs1
Audio Outputs1
Audio bidirectional (Full-duplex)Yes
Network features
PoE ports8
Number of ports RJ451
Speed RJ4510 / 100 / 1000 Mbps
Maximum number of users128
Mobile devicesAndroid / IOS (Apple)
Remote visionWeb Browser / Smartphone App and Hik-Connect Software.
Type PoE802.3at / af
PoE consumption120W
SoftwareIVMS
AppHik-Connect
Reproduction and copy of security
Smart searchYes
Synchronized playback8
Storage
Number of supported hard drives2
Maximum hard disk size (Unit)10 TB
Type HDD3,5 SATA"
Intelligent video system
POSYes
VCASí
Motion detectionYes
Perimeter protection
Channels number with analytics4 channels / 12 IVS rules for each channel
Type of identification Human secondary recognition / vehicle for line crossing and intrusion
Face Recognition
Number of faces4 faces processed per second
Database managmentUp to 16 databases with 10,000 faces in total / Allows designating name / gender / birth date / nationality / address / Identification information can be added to each face image
