MOVOK
VK-NVR2104
IP recorder of 4 channel and 8 mpx resolution
- IP Channels: 4
- Maximum recording resolution: 8 Mpx
- Input bandwidth: 96 Mbps
- Number of supported hard drives: 1
Sign in to see the price
Quantity1
- 1
Inputs/Outputs
USB 2.0: 2
- 2
Recording
Maximum recording resolution: 8 Mpx
Input bandwidth: 96 Mbps
Output bandwidth: 96 Mbps
- 3
Video output
HDMI Output Number: 1
Number of VGA outputs: 1
- 4
Network features
Number of ports RJ45: 1
Speed RJ45: 100 Mbps
- 5
Storage
Number of supported hard drives: 1
Maximum hard disk size (Unit): 14 TB
MOVOK
VK-NVR2104
specifications and features
General information
SerieSerie 2
TechnologyIP
Power consumption
Power modeDC
Voltage12V
Consumption (w)7W
Amperage2000mA
Ambient
Operating temperature-10 ºC ~ 55 ºC
UseIndoor
Maximum humidity90%
Material and dimensions
Dimensions235 x 215 x 45 mm
MaterialMetal
Net weight770 g
Weight with packaging1270 g
ChassisMini 1U
Inputs/Outputs
USB 2.02
Video
IP Channels 4
Recording
Maximum recording resolution8 Mpx
Input bandwidth96 Mbps
Video compressionH.265 / H.264
Recording modeGeneral / motion detection / intelligent / alarm
Audio compressionG.711A
Audio sampling frequency8KHz, 16 bit per channel
Output bandwidth96 Mbps
Video output
HDMI Output Number1
Number of VGA outputs1
Resolution HDMI4K
VGA resolution1080P
Audio
Audio Inputs1
Audio Outputs1
Audio bidirectional (Full-duplex)Yes
Network features
Number of ports RJ451
Speed RJ45100 Mbps
Mobile devicesAndroid / IOS (Apple)
ONVIFYes
P2PYes
SoftwareMOVOK (CMS)
AppMOVOK
Reproduction and copy of security
Simultaneous cameras in reproduction1 / 4
Playback functionsPlay / Pause / Stop / Fast forward / Fast backward / Rewind / Play by frame / Full screen / Backup (cut/file) / Partially enlarge / Audio on/off
Backup modeUSB
Smart searchYes
Synchronized playback4
Storage
Number of supported hard drives1
Maximum hard disk size (Unit)14 TB
Type HDD3,5 SATA"
System (Recorders)
Operating systemEmbedded LINUX
