Bullet ip camera of 4 megapixels and optical zoom lens
HIKVISION PRO

DS-2CD2643G2-LIZS2U(2.8-12mm)

Bullet ip camera of 4 megapixels and optical zoom lens

  • Video Resolution: 4 Megapixels
  • Lens Type: Optical zoom
  • Serie: Acusense
  • Focal distance: 2.8 mm ~ 12 mm

Sign in to see the price

Quantity1

accessories

Connections box

DS-1260ZJ

Corner mount

DS-1276ZJ-SUS

Mast / lamppost mount

DS-1275ZJ-SUS

Product exploded view
  1. 1

    Ambient

    Degree of protection: IP67

    Anti vandal: IK10

  2. 2

    Night vision

    Night vision distance: 60 m

    Type of night vision: Dual light (IR+Luz blanca)

  3. 3

    Lens

    Lens Type: Optical zoom

    Focal distance: 2.8 mm ~ 12 mm

  4. 4

    Video (Cameras)

    Video Resolution: 4 Megapixels

  5. 5

    Video analysis

    Detection type: Analytical with human/vehicle classification in line/area crossing

  6. 6

    Storage

    MicroSD-Card: Hasta 512Gb

detect

fixed lensvarifocal lens

64 m / 198 m

perception of moving objects without classifying them

observe

fixed lensvarifocal lens

25 m / 79 m

differentiation between people, animals or vehicles

recognise

fixed lensvarifocal lens

13 m / 40 m

distinction between a man or a woman

identify

fixed lensvarifocal lens

16 m / 20 m

facial identification, number plate visualisation

HIKVISION PRO

DS-2CD2643G2-LIZS2U(2.8-12mm)

specifications and features

General information

SerieAcusense
TechnologyIP
Type of cameraBullet


SensorCMOS ®
Sensor resolution2688 x 1520
Sensor Size1/3'
Electronic shutter speed 1/3 ~ 1/100000s
Minimum lighting0.005Lux
Ratio S / NMás de 52dB

Power consumption

Power modeDC
Voltage12V
Consumption (w)13W
Amperage1080mA
PoE powerYes
Type PoEPoE+ 802.3at

Ambient

Operating temperature-30 ºC ~ 60 ºC
Degree of protectionIP67
Anti vandalIK10
UseIndoor-outdoor
Maximum humidity95%

Night vision

Night vision distance60 m
Type of night visionDual light (IR+Luz blanca)
Smart IRYes
White lightSí
White light distance60 m
Wavelength850 nm
Smart Hybrid LightYes (switches from IR to colour with human detection)

Material and dimensions

Dimensions298 x 97.9 x 95.7 mm
MaterialMetal
Net weight1530 g
Weight with packaging1920 g
ColorWhite

Lens

Lens TypeOptical zoom
Focal distance2.8 mm ~ 12 mm
Maximum diaphragm openingF/1.6 ~ F/4.4
Angle of View102.4° ~ 31.2°
Filtro IRSí

DISTANCE DORI

Detect (Open lens)64 m
Detect (Closed Lens)198 m
Observe (Open lens)25 m
Observe (Closed lens)79 m
Recognize (Open lens)13 m
Recognize (Closed lens)40 m
Identify (Open lens)16 m
Identify (Closed lens)20 m

Axes

Motion3-Axis

Video (Cameras)

Video Resolution4 Megapixels
BLCYes
HLCYes
3D-NRYes
WDRWDR (120 dB)
Images per second25fps
Video outputRJ45
Day / night modeAutomatic / Manual
Privacy maskUp to 8 zones
Type of CodexCBR / VBR
Bit rate32Kbps ~ 8Mbps
CompressionH.265 / H.264
EISYes
Main stream4Mpx / 1080P / 720P (1 ~ 25fps)
Sub stream720P / 640 x 480 / 640 x 360 (1 ~ 25fps)
Sub stream 21080P / 720P / 640 × 480 / 640 × 360 (1 ~ 10fps)
MirrorOn / Off

AUDIO(CAMERAS)

Built in microphoneYes, dual array
Audio input1 Input
Audio compressionG.711A / G.711U / G.722.1 / G.726 / AAC / MP2L2 / MP3 / PCM
Noise filterSI
Sampling frequency8 kHz / 16 kHz / 32 kHz / 48 kHz
Bit rate 64 Kbps (G.711A / G.711U) / 16 Kbps (G.722.1 / G.726) / 16 ~ 64 Kbps (AAC) / 32 ~ 160 Kbps (MP2L2) / 8 ~ 320 Kbps (MP3)
Audio output1

Network features

IP connection1 RJ45 (10M / 100M)
ONVIFYes, type S y G
Maximum number of usersUp to 32 users
Password protectionYes
Web browserExplorer / Chrome / Firefox / Safari
Management softwareiVMS-4200 / Hik-Connect / Hik-Central
Mobile devicesAndroid / IOS (Apple)
Live viewUp to 6 channels
IP address filterYes

Video analysis

Detection typeAnalytical with human/vehicle classification in line/area crossing
AI FunctionsFacial detection
Crossing lineYes
IntrusionYes
Face detectionYes
Motion detectionYes
Video TamperYes
Classification Human / vehicleYes

Storage

MicroSD-CardHasta 512Gb
Storage Systems NAS / FTP / Micro SD
Storage anomalyYes
ANR (Redundant Recording in SD)Yes

System (Cameras)

Reset buttonYes

Inputs/Outputs (Cameras)

Alarm1 Input / 1 Output

DORI distance

Detect64 m / 198 m
Observe25 m / 79 m
Recognise13 m / 40 m
Identify16 m / 20 m
