HIKVISION
HWD-5116MH/T
5 in 1 (hd-cvi, hd-tvi, ahd, analog and ip) recorder of 16 channel and 2 mpx maximum resolution
- BNC channels: 16
- IP Channels: 18, replacing the BNC channels
- Maximum recording resolution: 2 Mpx
- Input bandwidth: 96 Mbps
Sign in to see the price
Quantity1
- 1
Inputs/Outputs
USB 2.0: 2
- 2
Recording
Maximum recording resolution: 2 Mpx
Input bandwidth: 96 Mbps
Output bandwidth: 96 Mbps
- 3
Video output
HDMI Output Number: 1
Number of VGA outputs: 1
- 4
Network features
Number of ports RJ45: 1
Speed RJ45: 10 / 100 Mbps
- 5
Storage
Number of supported hard drives: 1
Maximum hard disk size (Unit): 10 TB
HIKVISION
HWD-5116MH/T
specifications and features
General information
SerieHiWatch
Technology5 IN 1 (HD-CVI, HD-TVI, AHD, analog and IP)
Power consumption
Power modeDC
Voltage12V
Consumption (w)10W
Amperage1600mA
Ambient
Operating temperature-10 ºC ~ 55 ºC
UseIndoor
Maximum humidity90%
Material and dimensions
Dimensions263 x 225 x 48 mm
MaterialMetal
Net weight1100 g
Weight with packaging1430 g
Inputs/Outputs
USB 2.02
Video
BNC channels16
IP Channels 18, replacing the BNC channels
Video formatsHDCVI / TVI / AHD / CVBS / IP
Admitted resolutions HDCVI1080P / 720P
Admitted resolutions HDTVI1080P / 720P
Admitted resolutions AHD1080P / 720P
Cameras CVBSYes
Resolution IP cameras5 Megapíxeles
Recording
Maximum recording resolution2 Mpx
Input bandwidth96 Mbps
Video compressionH.265+ / H.265 / H.264+ / H.264
Resolution HDCVI recording2 Megapixel (1080p)
Resolution HDTVI recording2 Megapixel (1080p)
Resolution recording AHD2 Megapixel (1080p)
Images per second Main stream1080P Lite / 720P Lite / WD1 / 4CIF / VGA / CIF (1 ~15fps)
Images per second Extra streamCIF / QVGA (1 ~ 15fps)
Video bit rate32 Kbps ~ 4 Mbps
Audio compressionG.711U
Speed audio bits64Kbps per channel
Output bandwidth96 Mbps
Video output
HDMI Output Number1
Number of VGA outputs1
Resolution HDMI1080P
VGA resolution1080P
Similar video signalsHDMI and VGA
Audio
Audio Inputs1
Audio Outputs1
Audio bidirectional (Full-duplex)Yes
Network features
Number of ports RJ451
Speed RJ4510 / 100 Mbps
Maximum number of users128
Mobile devicesAndroid / IOS (Apple)
ONVIFYes
Remote visionWeb Browser / Smartphone App and Hik-Connect Software.
SoftwareIVMS
AppHik-Connect
Reproduction and copy of security
Smart searchYes
Synchronized playback16
Storage
Number of supported hard drives1
Maximum hard disk size (Unit)10 TB
Type HDD3,5 SATA"
Intelligent video system
Classification Human / vehicleYes
Motion detectionYes, 2.0 on all analogue channels
