HIKVISION
HWD-7104MH/T
5 in 1 (hd-cvi, hd-tvi, ahd, analog and ip) recorder of 4 channel and 8 mpx maximum resolution
- BNC channels: 4
- IP Channels: 6
- Maximum recording resolution: 8 Mpx
- Accepted IP cameras: 4 BNC cameras + 2 IP cameras
Sign in to see the price
Quantity1
- 1
Inputs/Outputs
USB 2.0: 2
- 2
Recording
Maximum recording resolution: 8 Mpx
- 3
Video output
HDMI Output Number: 1
Number of VGA outputs: 1
- 4
Network features
Number of ports RJ45: 1
Speed RJ45: 10 / 100 Mbps
- 5
Storage
Number of supported hard drives: 1
Maximum hard disk size (Unit): 10 TB
HIKVISION
HWD-7104MH/T
specifications and features
General information
SerieHiWatch
Technology5 IN 1 (HD-CVI, HD-TVI, AHD, analog and IP)
Power consumption
Power modeDC
Voltage12V
Consumption (w)15W
Amperage1500mA
Ambient
Operating temperature-10 ºC ~ 55 ºC
UseIndoor
Maximum humidity90%
Material and dimensions
Dimensions263 x 225 x 48 mm
MaterialMetal
Net weight1160 g
Weight with packaging1330 g
Inputs/Outputs
USB 2.02
Video
BNC channels4
IP Channels 6
Accepted IP cameras4 BNC cameras + 2 IP cameras
Video formatsHDCVI / TVI / AHD / CVBS / IP
Admitted resolutions HDCVI8 Megapíxeles
Admitted resolutions HDTVI8 Megapíxeles
Admitted resolutions AHD5 Megapíxeles
Cameras CVBSYes
Resolution IP cameras8 Megapíxeles
Recording
Maximum recording resolution8 Mpx
Video compressionH.265 / H.264
Resolution HDCVI recording8 Megapixel (4K)
Resolution HDTVI recording8 Megapíxeles
Resolution recording AHD5 Megapíxeles
Images per second Main stream1080P / 720P (15fps) / VGA / WD1 / 4CIF / CIF (25 fps)
Images per second Extra streamWD1 / 4CIF / CIF (25fps)
Video bit rate32 Kbps ~ 10 Mbps
Audio compressionG.711U
Speed audio bits64Kbps per channel
Video output
HDMI Output Number1
Number of VGA outputs1
Resolution HDMI4Mpx
VGA resolution1080P
Similar video signalsHDMI and VGA
Audio
Audio Inputs1
Audio Outputs1
Audio bidirectional (Full-duplex)Yes
Network features
Number of ports RJ451
Speed RJ4510 / 100 Mbps
Maximum number of users32
Mobile devicesAndroid / IOS (Apple)
ONVIFYes
Remote visionWeb Browser / Smartphone App and Hik-Connect Software.
SoftwareIVMS
AppHik-Connect
Reproduction and copy of security
Smart searchYes
Synchronized playback4
Storage
Number of supported hard drives1
Maximum hard disk size (Unit)10 TB
Type HDD3,5 SATA"
Intelligent video system
Classification Human / vehicleYes
Motion detectionYes, 2.0 on all analogue channels
