5 in 1 (hd-cvi, hd-tvi, ahd, analog and ip) recorder of 16 channel and 2 mpx maximum resolution
DAHUA

XVR5116HS-I3/T

5 in 1 (hd-cvi, hd-tvi, ahd, analog and ip) recorder of 16 channel and 2 mpx maximum resolution

  • BNC channels: 16
  • IP Channels: 24, replacing the BNC channels
  • Maximum recording resolution: 2 Mpx
  • Accepted IP cameras: 16 BNC cameras + 8 IP cameras

Sign in to see the price

Quantity1
Product exploded view
  1. 1

    Inputs/Outputs

    USB 2.0: 1

    USB 3.0: 1

  2. 2

    Recording

    Maximum recording resolution: 2 Mpx

  3. 3

    Video output

    HDMI Output Number: 1

    Number of VGA outputs: 1

  4. 4

    Network features

    Number of ports RJ45: 1

    Speed RJ45: 10 / 100 / 1000 Mbps

  5. 5

    Storage

    Number of supported hard drives: 1

    Maximum hard disk size (Unit): 16 TB

DAHUA

XVR5116HS-I3/T

specifications and features

General information

SerieWiz Sense
Technology5 IN 1 (HD-CVI, HD-TVI, AHD, analog and IP)

Power consumption

Power modeDC
Voltage12V
Consumption (w)12W
Amperage2000mA

Ambient

Operating temperature-10 ºC ~ 55 ºC
UseIndoor
Maximum humidity90%

Material and dimensions

InstallationDesktop
Dimensions260 x 237.8 x 47.6 mm
MaterialMetal
Net weight1000 g
Weight with packaging1590 g
ChassisCompact 1U

Inputs/Outputs

USB 2.01
USB 3.01
RS4851

Video

BNC channels16
IP Channels 24, replacing the BNC channels
Accepted IP cameras16 BNC cameras + 8 IP cameras
Video formatsHDCVI / TVI / AHD / CVBS / IP
Admitted resolutions HDCVI5Mpx / 4Mpx / 2Mpx / 1Mpx
Admitted resolutions HDTVI5Mpx / 4Mpx / 2Mpx / 1Mpx
Admitted resolutions AHD5Mpx / 4Mpx / 2Mpx / 1Mpx
Cameras CVBSYes
Resolution IP cameras6 Megapíxeles

Recording

Maximum recording resolution2 Mpx
Video compressionH.265+ / H.265 / H.264+ / H.264
Resolution HDCVI recording2 Megapixel (1080p)
Resolution HDTVI recording2 Megapixel (1080p)
Resolution recording AHD2 Megapixel (1080p)
Images per second Main stream5Mpx-N (1 ~ 20fps / 12fps) / 4Mpx-N / 1080P (1 ~ 25fps / 15fps) / 1080N / 720P / 960H / D1 / CIF (1 ~ 30fps)
Images per second Extra streamD1 / CIF (1 ~ 15fps)
Video bit rate32Kbps ~ 6144Kbps per channel
Recording modeGeneral / motion detection / intelligent / alarm
Audio compressionG.711A / G.711U / PCM
Audio sampling frequency8KHz, 16 bit per channel
Speed audio bits64Kbps per channel

Video output

HDMI Output Number1
Number of VGA outputs1
Resolution HDMI4K
VGA resolution1080P

Audio

Audio Inputs1
Audio Outputs1
Audio bidirectional (Full-duplex)Yes

Network features

Number of ports RJ451
Speed RJ4510 / 100 / 1000 Mbps
Mobile devicesAndroid / IOS (Apple)
ONVIFYes
Remote visionWeb Browser (ActiveX) / Smartphone App / Smart PSS Software
P2PYes
SoftwareSmartPSS
AppiDMSS / gDMSS

Reproduction and copy of security

Backup modeUSB / Network device
Smart searchYes
Nº canales simultáneos con cámaras IP 1 / 4 / 8 / 9 / 16 / 25
Nº canales simultáneos sin cámaras IP 1 / 4 / 8 / 9 / 16
Synchronized playback1 / 4 / 9 / 16

Storage

Number of supported hard drives1
Maximum hard disk size (Unit)16 TB
Type HDD3,5 SATA"

System (Recorders)

ProcessorIndustrial grade integrated processor
Operating systemEmbedded LINUX

Intelligent video system

Facial recognitionYes
VQD (Diagnosis video quality)Yes, 16 AI-powered channels
Change of sceneYes
Face detectionYes
Protección de perímetroSí
SMD PLUSYes, 16 channels (human / vehicle classification) (analog cameras only)
Classification Human / vehicleYes
Motion detectionYes
Video TamperYes
Acupick (intelligent object search)Yes

Perimeter protection

Channels number with analytics2 channels / 10 IVS rules for each channel (analog cameras only)

Face Recognition

Number of channels with facial recognition2 channel video facial recognition (only analog cameras)
Database managmentHasta 10 bases de datos con 10.000 rostros en total
