AJAX
NVR216-HAC-16P-W
NVR216-HAC-16P-W
Sign in to see the price
Quantity1
AJAX
NVR216-HAC-16P-W
specifications and features
General information
SerieH2D serie baseline
TechnologyIP
CompatibilityAjax cameras / IP cameras compatible with ONVIF and RTSP profiles
Power consumption
Power modeAC
Voltage100V ~ 240V
Consumption (w)320W
Amperage5000mA
Ambient
Operating temperature0 °С ~ 50 °С
Degree of protectionIP20
UseIndoor
Maximum humidity75%
Material and dimensions
Dimensions330 x 330 x 44 mm
Net weight2800 g
Weight with packaging4300 g
ColorWhite
Inputs/Outputs
USB 2.03
Video
IP Channels 16
ONVIFYes, S-type
RTSPYes
Recording
Maximum recording resolution12 Mpx
Input bandwidth160Mbps
Video compressionH.265 / H.264
Channels that support the maximum recording resolution12Mpx on 2 channels only
Output bandwidth160Mbps
Video output
HDMI Output Number1
Resolution HDMI4K
Network features
PoE ports16
ProtocolJetSparrow
Number of ports RJ451
Speed RJ4510 / 100 / 1000 Mbps
Type PoE802.3at / af
PoE consumption25W per port / 160W in total
AppAjax Security System
Reproduction and copy of security
Synchronized playback4
Storage
Number of supported hard drives2
Maximum hard disk size (Unit)16 TB
Type HDD3,5 SATA"
Intelligent video system
Motion detectionYes
Búsqueda por eventoYes
Grupo de escenariosSí, entre cámaras y otros dispositivos AJAX
